2 Bottom HYD Reversible Plough

HYD Reversible Plough
HYD Reversible Plough

2 Bottom HYD Reversible Plough

  1. Reversible MB plough uses for break & inverse the hard soil where other implements can not penetrate.
  2. It has a pair of 2 sets of MB ploughs which can be changed or reversed to work in both directions.
  3. Reversing of the furrow easily done by hydraulic actuation mechanism.
  4. Since two furrows are used it reduces ploughing time.
  5. It lifts the soil-clod and throws it on the soil surface breaking the soil-clod into smaller particle size.
  6. Easy connectivity to tractor hydraulic control valve & easy to mount on tractor three-point hitch system
Categories: ,

Description

Specification

Model Number 8MBHRP 10MBHRP Unit
Overall Length 1620 1620 mm
Over Width 820 910 mm
Overall Height 980 1050 mm
Number of boards 2 Nos.
Complete width of cut 500-630 630-700 mm
Depth of Cut 150-200 mm
Mould Board 6 mm
Suitable HP range 18-25 HP
Weight 150 230 Kg.
